SYNC 3.4 from SYNC 2 Voice Commands

Ford AsBuilt
, , , , , ,
1

Hi there,
I am UK based with a 2016 Ford Ranger 3.2 Auto. It came with the SYNC 2 unit which I have upgraded with an Ebay acquired SYNC 3 that has been upgraded to SYNC 3.4 using CYANLABS.

Post install I have found that the Voice command button on the steering wheel no longer functions (at all) and also the clock, although present at start up, disappears after a few seconds.

Having read many posts here and on Google it would appear that I need to tweak some vallues in the APIM via Forscan, I just don’t know what new values to write.

Can anyone help please?

SYNC Region: EU

Navigation Variant: Nav

Manufacturer Year: Pre MY20

Install Type: Retrofit

Old SYNC Version: 2

New SYNC Version: 3.4.23188

Do you have a error message, if so what is it?
Only error meaage is the navigation faulty one which quickly disappers

Update Method: CyanLabs Syn3 Updater

Syn3 Updater Version: unknown

Syn3 Updater Documentation Read: yes

Syn3 Updater Log File

This is the APIM log file from the AS Built:

;Block 1
7D0G1G10B6865DA109B
7D0G1G2021E1B004459
;Block 2
7D0G2G1554B0A06008A
7D0G2G20309000000E7
7D0G2G30600E2
;Block 3
7D0G3G1025437000068
;Block 4
7D0G4G10100000000DD
7D0G4G20001DE
;Block 5
7D0G5G11AC21AA42BA2
7D0G5G2D0AE
;Block 6
7D0G6G1805E
;Block 7
7D0G7G1070033000019
7D0G7G20000171C0013
7D0G7G30056566D00FA
7D0G7G46A4C
;Block 8
7D0G8G1800000000060
7D0G8G20000000010F1
;Block 9
7D0G9G1000000400021
7D0G9G20000000000E2
7D0G9G30000000000E3
7D0G9G40000000000E4
2

That APIM log is for your old Sync 2 system. Now that you’re on Sync 3 all of those values are wrong and irrelevant.

You need to post your current AB values that you Sync 3 APIM has.

3

That is the log from the currently installed APIM system SYNC 3.4

1 Like
4

Likely the master clock and steering wheel control settings.

5

Thank you.
I kind of figured that but don’t know what the changes should be to make it function properly.

As an example I found this:

Screenshot_20241202_092744_Chrome
Screenshot_20241202_092744_Chrome1041×377 56.4 KB

But how would I know what to change it to to make it function correctly?

Any insights please?

6

No one able to help me out here?

7

Find a VIN of a car with SYNC 3 with the same features as your car, get the asbuilt for that VIN and then use that on your car.

Not related to SYNC Update, moving to Asbuilt.

8

Appreciate the response.

Now the hunt is on as trucks aren’t quite as commonplace here as in The States.

Many thanks
